Transceiver (1-56G)

Optical Transceiver (1-56G)



10Gtek® is a trusted supplier of optical transceivers, who researches, designs, manufactures and markets optical transceivers for various applications & data rate. In accordance with IEEE and MSA protocol, the transceivers use the form factor of SFP, SFP+, SFP28, QSFP+, QSFP28, QSFP-DD, CFP, CFP2, CFP4, OSFP, etc.

We focus on providing modules with fast delivery, high-reliable design and quality control, low power consumption design and flexible brands compatibility.

SFP ( < 2.5G)

SFP ( < 2.5G)

10Gtek has the Ethernet modules you need:

100M SFP for Fast Ethernet application, 1.25G SFP for Gigabit Ethernet application, SDH/SONET SFP for STM-1/ 4/ 16 or OC-3/ 12/ 48, Fiber Channel for FC/ FC2/ FC4/ FC8/ FC16.

10Gtek's transceivers are based on IEEE 802.3z and MSA SFF-8032, SFF-8079, SFF-8089, SFF-8085, SFF-8074, SFF-8686.



SFP+ (10G )

SFP+ (10G )

10Gtek® 10G SFP+ transceivers include -T, SR, LR, LRM, ER, ZR, and C/DWDM, BiDi series .

10G SFP+ transceivers are compliant with IEEE802.3ae, SFF-8083, SFF-8472 and SFF-8431, SFF-8461, with features of Low Power Consumption.

They are designed for applications of Data Centers, Metro Network, Wireless Network and Transmission network.

SFP28 (25G)

SFP28 (25G)

10Gtek 25G SFP28 transceivers include SR, LR, BiDi, CWDM and DWDM series.

The 25G SFP28 transceivers are compliant with IEEE 802.3by and MSA SFF-8402.

XFP (8~10G)

XFP (8~10G)

10Gtek 10G XFP transceivers include SR, LR, ER, ZR, CWDM, DWDM and BiDi series. Tunable XFP modules are available.
10G XFP transceivers are compliant with 10 Gigabit Ethernet, 10 Gbit/s Fibre Channel, SONET at OC-192 rates, SDH at STM-64, 10 Gbit/s Optical Transport Network (OTN) OTU-2, and parallel optics links.
SFP (FC8/16/32)

SFP (FC8/16/32)

10Gtek® 16G SFP+ fibre channel transceivers are suitable for 16‍G fibre channel and 10G Ethernet applications. This fibre channel transceiver solution supports high-speed serial links over multimode single mode fiber at signaling rates up to 14.025 Gb/s.

10Gtek®  32G SFP28 fibre channel transceivers are suitable for fibre channel and 25G Ethernet applications. They are designed for use in 25/28G Gb/s links over multimode or single mode fiber. They are compliant to IEEE 802.3by, SFF-8472 Rev 12.2 and SFF-8402, and compatible with SFF-8432 and applicable portions of SFF-8431 Rev. 4.1.



QSFP+ (40/56G)

QSFP+ (40/56G)

10Gtek 40G QSFP+ transceivers include SR4, eSR4, LX4, LR4 Lite, IR4 PSM, LR4 PSM, LR4, ER4 and BiDi series.
10Gtek 56G QSFP+ transceivers are compliant with InfiniBand FDR/QDR/DDR/SDR.
QSFP+ transceivers are compliant with IEEE 802.3ba and MSA SFF-8436.
QSFP28 (100G)

QSFP28 (100G)

10Gtek 100G QSFP28 transceivers include SR4, LR4, IR4 PSM, CWDM4 series.
The 100G QSFP28 transceivers are compliant with IEEE 802.3bm and MSA SFF-8665.
CFP4 (100G)

CFP4 (100G)

10Gtek's CFP4 LR4 is a 100Gb/s transceiver module for optical communication applications compliant to 100GBASE-LR4 of the IEEE P802.3ba standard. The module converts 4 input channels of 25Gb/s electrical data to 4 channels of LAN WDM optical signals and then multiplexes them into a single channel for 100Gb/s optical transmission. Reversely on the receiver side, the module de-multiplexes a 100Gb/s optical input into 4 channels of LAN WDM optical signals and then converts them to 4 output channels of electrical data.
The product is designed with the form factor, optical/electrical connection and MDIO interface according to the CFP4 Multi-Source Agreement (MSA). The innovative design has all the fibers inside the CFP4 package configured without any splicing or non-permanent connector. Also, fiber routines are neatly organized and fixed inside a stainless steel container.

QSFP-DD (200G/400G)

QSFP-DD (200G/400G)

10Gtek 400G QSFP-DD optical transceivers is available at 10Gtek.
