QSFP+ Extender (up to 80KM)

APPLICATIONS

QSFP+ long distance link
InfiniBand 4X SDR, DDR, QDR and FDR
Ethernet 10G, 40G
FiberChannel 10G, 40G, SAN, 4X16G
Rack-to-Rack, Shelf-to-Shelf Interconnect
Top of Rack (TOR) and Core Switch

STANDARDS COMPLIANCE

QSFP+ End
Electrical: IBTA V2 Revision 1.2.1 and 1.3
IEEE 802.3ba
SFF-8436
SFP+ End
SFF-8431
SFF-8432
SFF-8472
RoHS

10Gtek's QSFP+ Extender is used for long-distance transmission under 40G QSFP+. The QSFP+ Port could be transferred/converted into 4x SFP+ port by Direct Attach Copper (DAC) technology under very low insert lose.

10Gtek's QSFP+ Extender are provided in 1U rack and movable version with 3.3V power supply. Transmission distance could be extended longer by connecting with Standard SFP+ Transceivers.


Application:

Figure 1: To transmit up to 80km distance using the QSFP+ extender.

Qsfp+ Extender Apptication figure1
  • From switch to QSFP+ extender, connect the QSFP+ ports with either QSFP+ DAC or QSFP+ AOC or QSFP+ transceiver.
  • Between two extenders, connect the 4x SFP+ ports with SFP+ transceivers.
  • Use SFP+ ZR transceivers to achieve 80km transmission.

Figure 2: To save fiber using QSFP+ extender.

Qsfp+ Extender Apptication figure1
  • From switch to QSFP+ extender, connect the SFP+ ports with either SFP+ DAC or SFP+ AOC or SFP+ transceiver.
  • Between two extenders, connect the QSFP+ ports with QSFP+ transceivers.
  • Use QSFP+ LR4 to achieve 10km transmission with only one LC fiber.


Mechanical Dimensions:

CVT-Q01-Oxx
QSFP+ Extender Box

Qsfp+ Extender Apptication figure1

CVT-OEO-Q/4S
QSFP+ Extender for 1U

Qsfp+ Extender Apptication figure1


Ordering Information:

Part Number Description
CVT-OEO-Q/4S0C QSFP+ to 4x SFP+ Extender, for 1U Chassis, passive
CVT-OEO-Q/4S1C QSFP+ to 4x SFP+ Extender, for 1U Chassis, active, with cdr
CVT-Q01-030 QSFP+ to 4x SFP+ Extender box, 30cm QSFP+ pigtail
CVT-Q01-050 QSFP+ to 4x SFP+ Extender box, 50cm QSFP+ pigtail
