10Gtek's 100Gb/s QSFP28 AOC is a high data rate parallel active optical cable (AOC), to overcome the bandwidth limitation of traditional copper cable. The AOC offers 4 independent data transmission channels and 4 data receiving channels via the multimode ribbon fibers, each capable of 25Gb/s operation. Consequently, an aggregate data rate of 100Gb/s over 100 meters transmission can be achieved by this product, to support the ultra-fast computing data exchange.The product is designed with the form factor, the optical/electrical connection according to the QSFP Multi-Source Agreement (MSA). It has been designed to meet the harshest external operating conditions including temperature, humidity, and EMI interference.

Four-channel full-duplex active optical cable
Multirate capability: 10 Gb/s to 28 Gb/s per channelQSFP28 high-density form factor
Reliable VCSEL array technology using multimode fiber
Round OFNP-rated cable
Hot PluggableLow power dissipation: <3.5W per cable end (<2.5W with CDRs off)
Commercial operating case temperature range: 0oC to 70oC
UL certification optional cables
RoHS-6 Compliant
Infiniband 4xEDR, 4xFDR, 4xQDR
10/25/40/100G Ethernet
4G/8G/16G/32G Fibre Channel
Proprietary HPC Interconnections
