AOC-Q4Q4-010

QSFP28 to QSFP28 AOC

10Gtek's 100Gb/s QSFP28 AOC is a high data rate parallel active optical cable (AOC), to overcome the bandwidth limitation of traditional copper cable. The AOC offers 4 independent data transmission channels and 4 data receiving channels via the multimode ribbon fibers, each capable of 25Gb/s operation. Consequently, an aggregate data rate of 100Gb/s over 100 meters transmission can be achieved by this product, to support the ultra-fast computing data exchange.The product is designed with the form factor, the optical/electrical connection according to the QSFP Multi-Source Agreement (MSA). It has been designed to meet the harshest external operating conditions including temperature, humidity, and EMI interference.

order
4 independent full-duplex channels
Up to 28Gb/s data rate per channel
QSFP MSA compliant
70m on OM3 MMF and 100m on OM4 MMF
Operating case temperature: 0 to 70oC
Single 3.3V power supply
Maximum power consumption 3.5W each terminal
RoHS-6 compliant
100G Ethernet
Infiniband EDR
